How to replace Samsung Galaxy S20 FE screen?

How to replace Samsung Galaxy S20 FE screen?

The Samsung Galaxy S20 FE is a smartphone that was released in 2020 by Samsung. It is a more affordable version of the Galaxy S20 series, but it still has many of the same features and specifications. The Galaxy S20 FE has a 6.5-inch Super AMOLED display with a resolution of 1080 x 2400 pixels and a pixel density of 407 PPI. It also has a fingerprint sensor under the display and a hole-punch cutout for the selfie camera. The display supports HDR10+, 120Hz refresh rate, and Gorilla Glass 3 protection. The Galaxy S20 FE has a triple rear camera setup that consists of a 12 MP wide-angle lens, an 8 MP telephoto lens, and a 12 MP ultra-wide lens. The camera can record 8K videos at 24 fps and has features like HDR10+, super steady video, and live focus. The Galaxy S20 FE runs on either the Qualcomm Snapdragon 865 or the Samsung Exynos 990 chipset, depending on the region. It has 6 GB or 8 GB of RAM, 128 GB or 256 GB of internal storage, and a microSD card slot that can support up to 1 TB of additional storage. The Galaxy S20 FE has a non-removable Li-Po 4500 mAh battery that supports fast charging, wireless charging, and reverse wireless charging. It also has other features like IP68 water and dust resistance, stereo speakers, NFC, and USB Type-C port.

The Galaxy S20 FE is one of the most powerful and innovative smartphones of 2020. It offers a premium design, a stunning display, a versatile camera, a fast performance, and a long-lasting battery. It is also one of the first smartphones to support Wi-Fi 6, which is the latest and fastest Wi-Fi standard. The Galaxy S20 FE is available in various colors, such as Cloud Lavender, Cloud Mint, Cloud Navy, Cloud White, Cloud Red, and Cloud Orange

πŸ› οΈThe Galaxy S20 FE screen one of the best and most advanced screens in the market

But they also make it more expensive and difficult to replace.

The answer is YES, but the process may vary depending on the extent of the damage and the availability of spare parts. The Galaxy S20 FE screen consists of an AMOLED display and a digitizer, which are fused together as a single unit. If either of these components is broken, the whole screen unit needs to be replaced.

πŸ“ŒStep-by-Step Guide to Replace Screen of Samsung Galaxy S20 FE

Replacing the screen of a Samsung Galaxy S20 FE smartphone may seem daunting at first, but with the right tools, patience, and following this detailed guide, you can successfully complete the process. It's important to note that attempting this repair could void your warranty, and there is a risk of damaging other internal components. Take necessary precautions, work slowly and carefully, and be mindful of the potential challenges ahead. Let's get started!

Tools needed:

1. Small Phillips screwdriver
2. Plastic pry tool or guitar pick
3. Suction cup tool
4. Tweezers
5. Heat gun or hairdryer (optional, but recommended)


- Backup your data: Ensure important data is backed up to avoid any loss during the repair process.
- Avoid electrostatic discharge: Before starting, use an anti-static wrist strap or touch a grounded metal object to discharge static electricity.
- Work in a clean, well-lit area: Keep the workspace organized and free of any debris that could obstruct the process or damage delicate components.

Step 1: Power off the device
- Press and hold the power button until the power options appear on the screen.
- Tap "Power off" and wait for the device to shut down completely.

Step 2: Remove the SIM card tray
- Locate the SIM card tray on the top edge of the phone.
- Insert the eject tool or a paperclip into the small hole next to the tray.
- Apply gentle pressure to eject the tray.

Step 3: Heat the back cover (optional)
- Using a heat gun or hairdryer, warm the back cover of the device for 1-2 minutes. This helps soften the adhesive securing the back cover.
- This step is optional but recommended for easier removal.

Step 4: Remove the back cover
- Place the suction cup tool on the back cover near any corner.
- Apply firm, steady pressure to lift the back cover slightly.
- Insert a plastic pry tool or guitar pick between the back cover and the frame.
- Slowly slide the pry tool around the edges of the device, releasing the clips securing the back cover.
- Be careful not to insert the tool too far, as it may damage internal components or cables.

Step 5: Disconnect the battery connector
- Locate the battery connector on the motherboard.
- Use a small Phillips screwdriver to remove the screws holding the connector in place (usually 1 or 2 screws).
- Gently lift the connector straight up to detach it from the motherboard.

Step 6: Disconnect other connectors
- Carefully disconnect the ribbon cables connected to the motherboard by gently lifting them with a pair of tweezers or a plastic pry tool.
- Take care not to apply excessive force as these cables are delicate.

Step 7: Remove the motherboard
- Remove all remaining screws securing the motherboard using a small Phillips screwdriver.
- Gently lift and remove the motherboard from the device, storing it in a safe place.

Step 8: Disconnect and remove the old screen assembly
- Disconnect the remaining ribbon cable(s) or connectors attached to the screen assembly.
- Locate the adhesive holding the screen to the frame.
- Slowly lift the screen assembly away from the frame.
- Take note of any cables or connectors that may still be attached and carefully disconnect them.

Step 9: Install the new screen assembly
- Connect any cables or connectors to the new screen assembly before placing it back into the device.
- Align the new screen assembly with the frame and gently press it into place.
- Ensure it is properly seated and flush with the frame.

Step 10: Reassemble the device
- Follow the previous steps in reverse order to reattach the motherboard, connectors, and secure all screws.
- Reconnect the battery connector and carefully reinsert any remaining ribbon cables.
- Place the back cover over the device, aligning it with the frame.
- Apply even pressure around the edges to secure the clips.

Step 11: Test the replacement screen
- Power on the device and test the functionality of the new screen.
- Check for any display abnormalities, touch responsiveness, and adjust if necessary.

πŸ’‘Troubleshooting Tips

- Ensure all connectors are securely seated and that no cables are pinched or damaged.
- If the screen doesn't respond after installation, double-check the connectors and reconnect if needed.
- If the screen appears dark or has discoloration, remove it and reapply it to ensure proper alignment and adhesive contact.

By following this step-by-step tutorial along with the provided high-resolution images, you should be able to successfully replace the screen of your Samsung Galaxy S20 FE smartphone. Remember to work slowly, be cautious, and take the necessary precautions to minimize the risks involved. With patience and attention to detail, you can save money and feel empowered by accomplishing this repair on your own.
